Microchip
Supporting the maker community with @MicrochipTech MCUs and other devices and tools to bring innovative ideas to life. Follow along as we share their projects!
22 Projects
Diagnostico
This is an intelligent patient monitoring solution that uses BLE to collect data from patients and a unique ML core that predicts body parameters like cholesterol using non-invasive techniques.
Midi Sequencer Using Thermal Camera
The Giant Board linux computer takes an 8x8 thermal image and displays it on the TFT while also assigning a musical note to each temperature. It plays a song corresponding to the temperature of the object.
Giant Board For Smart Iot Gateway In Drying System
Smart IoT Gateway could be used to collect the environmental condition in the drying system for an agricultural use cases.
Wireless Linux Data Logger
A linux based data logger over SSH Wireless made with Giant Board
Diy Attiny85 Digispark-inspired Traffic Light
A kids traffic light!
A Smarter Green Thumb
Horticulture is the art and science of plant and crop cultivation. Healthy gardens require attention and a knowledgeable, informed caretaker. Technology can help to empower the amateur gardener and professional farmer alike with data to ensure healthy crop yields. Microchip Xplained electronics are ripe to provide that type of i
Follow Me Light
use wifi singnal make light can auto on/off when you near it or leave.
Hacking Qualcomm (Quick Charge) QC 2.0/3.0 With ATtiny85
Get not only 5 volts but also 9, 12 volts (18 Watts max) out of any QC-compatible charger/power bank for supplying power hungry projects.
Real-time Laboratory Monitoring
Design and build a system to monitor the status of a Laboratory using the Microchip AVR-IoT WG Development Board.
Color Control For Rgbw Led Stripes
For using RGBW LED stripes properly, I was missing an easy control of color and brightness. Based on the PIC16F1827 I developed a control card using the serial line for communication and a Raspberry PI showing the Web based control page as part of my home control system.
Domestic Central Heating Radiator Efficiency Optimiser
IoT device to log input and output temperatures of a radiator. The plan is to get a display of temperature differential. One of the radiator valves can then be adjusted to change the water flow until an optimum drop is achieved. That is about 20F or 12C according to the Web, but Analytics on the data can help determine ideal.
All In One Led Light
Built Smart LED light with auto ON/OFF, brightness control and night mode using Microchip AVR iot WG development Board with Open Weather Maps and local time
Pwm On Mikrobus Header Of Avr Iot Wg
Atmel Start only support PWM functionality for ERR (Red), DATA (Yellow) and CONN (green) of AVR iot WG board. Here we will learn to configure TCA timer in split mode to enable PWM on mikroBUS header of this board.
Easy Ina219 Interfacing With Avr Iot Wg
The INA219B breakout board can measure both the high side voltage and DC current draw over I2C with 1% precision and help in solving the power-monitoring problems.
Pick-a-plant
Choose the right plant for you, using Pick-A-Plant. This IoT device will help you find the best match for every location, using Microchip's AVR-IoT WG Development Board.
Etc100
Design and implement a system to request data to a device via TCPIP using AVR-IoT WG developmentr board from Microchip
Solid State Protection System For Various Ac/dc Applications
CoolMOS based isolated AC or DC load controller with ZVS switching and short circuit, overload, over/under voltage & frequency protections
-
